Growing Retinal Nerve Cells in a Lab

Work could eventually lead to cell transplants for people blinded by glaucoma and MS.

Johns Hopkins researchers have developed a method to efficiently turn human stem cells into retinal ganglion cells, the type of nerve cells located within the retina that transmit visual signals from the eye to the brain. Death and dysfunction of these cells cause vision loss in conditions like glaucoma and multiple sclerosis.

“Our work could lead not only to a better understanding of the biology of the optic nerve, but also to a cell-based human model that could be used to discover drugs that stop or treat blinding conditions,” says study leader Donald Zack, M.D., Ph.D., the Guerrieri Family Professor of Ophthalmology at the Johns Hopkins University School of Medicine. “And, eventually it could lead to the development of cell transplant therapies that restore vision in patients with glaucoma and MS.”

The laboratory process, described in the journal Scientific Reports, entails genetically modifying a line of human embryonic stem cells to become fluorescent upon their differentiation to retinal ganglion cells, and then using that cell line for development of new differentiation methods and characterization of the resulting cells.

Diagram shows human retinal ganglion cells are shown at day 50.

Fluorescence microscopy: Human retinal ganglion cells are shown at day 50. Credit: Valentin Sluch.

Using a genome editing laboratory tool called CRISPR-Cas9, investigators inserted a fluorescent protein gene into the stem cells’ DNA. This red fluorescent protein would be expressed only if another gene was also expressed, a gene named BRN3B (POU4F2). BRN3B is expressed by mature retinal ganglion cells, so once a cell differentiated into a retinal ganglion cell, it would appear red under a microscope.

Next, they used a technique called fluorescence-activated cell sorting to separate out the newly differentiated retinal ganglion cells from a mixture of different cells into a highly purified cell population for study. The cells showed biological and physical properties seen in retinal ganglion cells produced naturally, says Zack.

Researchers also found that adding a naturally occurring plant chemical called forskolin on the first day of the process helped improve the cells’ efficiency of becoming retinal ganglion cells. The researchers caution that forskolin, which is also widely available as a weight loss and muscle building supplement and is touted as an herbal treatment for a variety of disorders, is not scientifically proven safe or effective for treatment or prevention of blindness or any other disorder.

“By the 30th day of culture, there were obvious clumps of fluorescent cells visible under the microscope,” says lead author Valentin Sluch, Ph.D., a former Johns Hopkins biochemistry, cellular and molecular biology student and now a postdoctoral scholar working at Novartis, a pharmaceutical company. Sluch completed this research at Johns Hopkins before transitioning to Novartis.

“I was very excited when it first worked,” Sluch says. “I just jumped up from the microscope and ran [to get a colleague]. It seems we can now isolate the cells and study them in a pure culture, which is something that wasn’t possible before.”

“We really see this as just the beginning,” adds Zack. In follow-up studies using CRISPR, his lab is looking to find other genes that are important for ganglion cell survival and function. “We hope that these cells can eventually lead to new treatments for glaucoma and other forms of optic nerve disease.”

To use these cells to develop new treatments for MS, Zack is working with Peter Calabresi, M.D., professor of neurology and director of the Johns Hopkins Multiple Sclerosis Center.

About this genetics research

This work was completed through the Wilmer Eye Institute’s Glaucoma Center of Excellence and its Stem Cell Ocular Regenerative Medicine Center, of which Zack is co-director.

Study co-authors were Chung-ha Davis, Vinod Ranganathan, Kellin Krick, Russ Martin, Cynthia Berlinicke, Nicholas Marsh-Armstrong and Hai-Quan Mao of Johns Hopkins; and Jeffrey Diamond and Justin Kerr of the National Institute of Neurological Disorders and Stroke.

Funding: This work was supported by grants from the Maryland Stem Cell Research Fund under grant number 2014-MSCRFI-0774; the National Institutes of Health under grant numbers T32-90040730, 1RO1EY02268001, 5T32EY007143, 5P30EY001765 and R01EY023754; and unrestricted funds from Research to Prevent Blindness Inc., the Guerreri Family Foundation, and Mr. and Mrs. Robert and Clarice Smith.

Source: Marin Hedin – Johns Hopkins Medicine
Image Source: The image is credited to Valentin Sluch
Original Research: Full open access research for “Differentiation of human ESCs to retinal ganglion cells using a CRISPR engineered reporter cell line” by Valentin M. Sluch, Chung-ha O. Davis, Vinod Ranganathan, Justin M. Kerr, Kellin Krick, Russ Martin, Cynthia A. Berlinicke, Nicholas Marsh-Armstrong, Jeffrey S. Diamond, Hai-Quan Mao & Donald J. Zack in Scientific Reports. Published online November 13 2015 doi:10.1038/srep16595


Abstract

Differentiation of human ESCs to retinal ganglion cells using a CRISPR engineered reporter cell line

Retinal ganglion cell (RGC) injury and cell death from glaucoma and other forms of optic nerve disease is a major cause of irreversible vision loss and blindness. Human pluripotent stem cell (hPSC)-derived RGCs could provide a source of cells for the development of novel therapeutic molecules as well as for potential cell-based therapies. In addition, such cells could provide insights into human RGC development, gene regulation, and neuronal biology. Here, we report a simple, adherent cell culture protocol for differentiation of hPSCs to RGCs using a CRISPR-engineered RGC fluorescent reporter stem cell line. Fluorescence-activated cell sorting of the differentiated cultures yields a highly purified population of cells that express a range of RGC-enriched markers and exhibit morphological and physiological properties typical of RGCs. Additionally, we demonstrate that aligned nanofiber matrices can be used to guide the axonal outgrowth of hPSC-derived RGCs for in vitro optic nerve-like modeling. Lastly, using this protocol we identified forskolin as a potent promoter of RGC differentiation.

“Differentiation of human ESCs to retinal ganglion cells using a CRISPR engineered reporter cell line” by Valentin M. Sluch, Chung-ha O. Davis, Vinod Ranganathan, Justin M. Kerr, Kellin Krick, Russ Martin, Cynthia A. Berlinicke, Nicholas Marsh-Armstrong, Jeffrey S. Diamond, Hai-Quan Mao & Donald J. Zack in Scientific Reports. Published online November 13 2015 doi:10.1038/srep16595
