Artificial intelligence tool vastly scales up Alzheimer’s research

Summary: A convolutional neural network algorithm is able to process an entire whole brain slice slide with 98.7% accuracy. The technology could help speed up the diagnosis of Alzheimer’s disease.

Source: UC Davis Health

Researchers at UC Davis and UC San Francisco have found a way to teach a computer to precisely detect one of the hallmarks of Alzheimer’s disease in human brain tissue, delivering a proof of concept for a machine-learning approach to distinguishing critical markers of the disease.

Amyloid plaques are clumps of protein fragments in the brains of people with Alzheimer’s disease that destroy nerve cell connections. Much like the way Facebook recognizes faces based on captured images, the machine learning tool developed by a team of University of California scientists can “see” if a sample of brain tissue has one type of amyloid plaque or another, and do it very quickly.

The findings, published May 15 in Nature Communications, suggest that machine learning can augment the expertise and analysis of an expert neuropathologist. The tool allows them to analyze thousands of times more data and ask new questions that would not be possible with the limited data processing capabilities of even the most highly trained human experts.

“We still need the pathologist,” said Brittany N. Dugger, PhD, an assistant professor in the UC Davis Department of Pathology and Laboratory Medicine at UC Davis and lead author of the study. “This is a tool, like a keyboard is for writing. As keyboards have aided in writing workflows, digital pathology paired with machine learning can aid with neuropathology workflows.”

In this study, she partnered with Michael J. Keiser, PhD, an assistant professor in UCSF’s Institute for Neurodegenerative Diseases and Department of Pharmaceutical Chemistry, to determine if they could teach a computer to automate the laborious process of identifying and analyzing tiny amyloid plaques of various types in large slices of autopsied human brain tissue. For this job, Keiser and his team designed a “convolutional neural network” (CNN), a computer program designed to recognize patterns based on thousands of human-labeled examples.

To create enough training examples to teach the CNN algorithm how Dugger analyzes brain tissue, the UCSF team worked with her to devise a method that allowed her to rapidly annotate or label tens of thousands of images from a collection half a million close-up images of tissue from 43 healthy and diseased brain samples.

Like a computer dating service that allows users to swipe left or right to label someone’s photo “hot” or “not,” they developed a web platform that allowed Dugger to look one-at-a-time at highly zoomed-in regions of potential plaques and quickly label what she saw there. This digital pathology tool — which researchers called “blob or not” — allowed Dugger to annotate more than 70,000 “blobs,” or plaque candidates, at a rate of about 2,000 images per hour.

The UCSF team used this database of tens of thousands of labeled example images to train their CNN machine-learning algorithm to identify different types of brain changes seen in Alzheimer’s disease. That includes discriminating between so-called cored and diffuse plaques and identifying abnormalities in blood vessels. The researchers showed that their algorithm could process an entire whole-brain slice slide with 98.7% accuracy, with speed only limited by the number of computer processors they used. (In the current study they used a single graphics card like those used by home gamers.)

The team then performed rigorous tests of the computer’s identification skills to make sure its analysis was biologically valid.

“It’s notoriously hard to know what a machine-learning algorithm is actually doing under the hood, but we can open the black box and ask it to show us why it made its predictions,” Keiser explained.

Keiser emphasized that the machine learning tool is no better at identifying plaques than Dugger, the neuropathologist who trained the computer to find them in the first place.

This shows two heads and binary code

To create enough training examples to teach the CNN algorithm how Dugger analyzes brain tissue, the UCSF team worked with her to devise a method that allowed her to rapidly annotate or label tens of thousands of images from a collection half a million close-up images of tissue from 43 healthy and diseased brain samples. The image is in the public domain.

“But it’s tireless and scalable,” he said. “It’s a co-pilot, a force multiplier that extends the scope of what we can accomplish and lets us ask questions we never would have attempted manually. For example, we can look for rare plaques in unexpected places that could give us important clues about the course of the disease.

To promote use of the tool, the researchers have made it and the study data publicly available online. This has already generated interactions with other researchers who have evaluated the data and the algorithms in their own labs. In the future, the researchers hope that such algorithms will become a standard part of neuropathology research, trained to help scientists analyze vast amounts of data, tirelessly seeking out patterns that could unlock new insights into causes and potential treatments for the disease.

Credit: UC Davis Health.

“If we can better characterize what we are seeing, this could provide further insights into the diversity of dementia,” Dugger said. “It opens the door to precision medicine for dementias.”

She added, “These projects are phenomenal examples of cross-disciplinary translational science; neuropathologists, a statistician, a clinician, and engineers coming together, forming a dialogue and working together to solve a problem.”

Other study authors included: Charles DeCarli, Lee-Way Jin and Laurel Beckett from UC Davis; Ziqi Tang of UCSF and Tsinghua University in Beijing, China, and Kangway V. Chuang of UCSF.

Funding: The study was funded by an NIH P30 AG010129, Paul G. Allen Family Foundation Distinguished Investigator Award and the China Scholarship Council.

The authors declare no conflicting interests.

About this neuroscience research article

UC Davis Health
Media Contacts:
Dorsey Griffith – UC Davis Health
Image Source:
The image is in the public domain.

Original Research: Open access
“Interpretable classification of Alzheimer’s disease pathologies with a convolutional neural network pipeline”. Ziqi Tang, Kangway V. Chuang, Charles DeCarli, Lee-Way Jin, Laurel Beckett, Michael J. Keiser & Brittany N. Dugger.
Nature Communications. doi:10.1038/s41467-019-10212-1


Interpretable classification of Alzheimer’s disease pathologies with a convolutional neural network pipeline

Neuropathologists assess vast brain areas to identify diverse and subtly-differentiated morphologies. Standard semi-quantitative scoring approaches, however, are coarse-grained and lack precise neuroanatomic localization. We report a proof-of-concept deep learning pipeline that identifies specific neuropathologies—amyloid plaques and cerebral amyloid angiopathy—in immunohistochemically-stained archival slides. Using automated segmentation of stained objects and a cloud-based interface, we annotate > 70,000 plaque candidates from 43 whole slide images (WSIs) to train and evaluate convolutional neural networks. Networks achieve strong plaque classification on a 10-WSI hold-out set (0.993 and 0.743 areas under the receiver operating characteristic and precision recall curve, respectively). Prediction confidence maps visualize morphology distributions at high resolution. Resulting network-derived amyloid beta (Aβ)-burden scores correlate well with established semi-quantitative scores on a 30-WSI blinded hold-out. Finally, saliency mapping demonstrates that networks learn patterns agreeing with accepted pathologic features. This scalable means to augment a neuropathologist’s ability suggests a route to neuropathologic deep phenotyping.
