With Training, People in Mind-Controlled Wheelchairs Can Navigate Normal, Cluttered Spaces

Summary: New brain-machine interface technology allows those who are immobile to control their wheelchairs through mind control. The BMI allows users to traverse natural and cluttered environments after training.

Source: Cell Press

A mind-controlled wheelchair can help a paralyzed person gain new mobility by translating users’ thoughts into mechanical commands.

On November 18 in the journal iScience, researchers demonstrate that tetraplegic users can operate mind-controlled wheelchairs in a natural, cluttered environment after training for an extended period.

“We show that mutual learning of both the user and the brain-machine interface algorithm are both important for users to successfully operate such wheelchairs,” says José del R. Millán, the study’s corresponding author at The University of Texas at Austin. “Our research highlights a potential pathway for improved clinical translation of non-invasive brain-machine interface technology.”

Millán and his colleagues recruited three tetraplegic people for the longitudinal study. Each of the participants underwent training sessions three times per week for 2 to 5 months.

The participants wore a skullcap that detected their brain activities through electroencephalography (EEG), which would be converted to mechanical commands for the wheelchairs via a brain-machine interface device.

The participants were asked to control the direction of the wheelchair by thinking about moving their body parts. Specifically, they needed to think about moving both hands to turn left and both feet to turn right.

Credit: Luca Tonin

In the first training session, three participants had similar levels of accuracy—when the device’s responses aligned with users’ thoughts—of around 43% to 55%. Over the course of training, the brain-machine interface device team saw significant improvement in accuracy in participant 1, who reached an accuracy of over 95% by the end of his training.

The team also observed an increase in accuracy in participant 3 to 98% halfway through his training before the team updated his device with a new algorithm.

The improvement seen in participants 1 and 3 is correlated with improvement in feature discriminancy, which is the algorithm’s ability to discriminate the brain activity pattern encoded for “go left” thoughts from that for “go right.”

The team found that the better feature discriminancy is not only a result of machine learning of the device but also learning in the brain of the participants. The EEG of participants 1 and 3 showed clear shifts in brainwave patterns as they improved accuracy in mind-controlling the device.

“We see from the EEG results that the subject has consolidated a skill of modulating different parts of their brains to generate a pattern for ‘go left’ and a different pattern for ‘go right,'” Millán says. “We believe there is a cortical reorganization that happened as a result of the participants’ learning process.”

This shows a person in a wheelchair
The improvement seen in participants 1 and 3 is correlated with improvement in feature discriminancy, which is the algorithm’s ability to discriminate the brain activity pattern encoded for “go left” thoughts from that for “go right.” Image is i the public domain

Compared with participants 1 and 3, participant 2 had no significant changes in brain activity patterns throughout the training. His accuracy increased only slightly during the first few sessions, which remained stable for the rest of the training period. It suggests machine learning alone is insufficient for successfully maneuvering such a mind-controlled device, Millán says

By the end of the training, all participants were asked to drive their wheelchairs across a cluttered hospital room. They had to go around obstacles such as a room divider and hospital beds, which are set up to simulate the real-world environment. Both participants 1 and 3 finished the task while participant 2 failed to complete it.

“It seems that for someone to acquire good brain-machine interface control that allows them to perform relatively complex daily activity like driving the wheelchair in a natural environment, it requires some neuroplastic reorganization in our cortex,” Millán says.

The study also emphasized the role of long-term training in users. Although participant 1 performed exceptionally at the end, he struggled in the first few training sessions as well, Millán says. The longitudinal study is one of the first to evaluate the clinical translation of non-invasive brain-machine interface technology in tetraplegic people.

Next, the team wants to figure out why participant 2 didn’t experience the learning effect. They hope to conduct a more detailed analysis of all participants’ brain signals to understand their differences and possible interventions for people struggling with the learning process in the future.

About this neurotech research news

Author: Press Office
Source: Cell Press
Contact: Press Office – Cell Press
Image: The image is in the public domain

Original Research: Open access.
Learning to control a BMI-driven wheelchair for people with severe tetraplegia” by José del R. Millán et al. iScience


Learning to control a BMI-driven wheelchair for people with severe tetraplegia


  • Three participants learned to drive a non-invasive BMI-actuated wheelchair
  • Direct transfer of learned BMI skills to wheelchair control
  • Subject learning and robotic intelligence are key to translational BMI-actuated robots


Mind-controlled wheelchairs are an intriguing assistive mobility solution applicable in complete paralysis. Despite progress in brain-machine interface (BMI) technology, its translation remains elusive.

The primary objective of this study is to probe the hypothesis that BMI skill acquisition by end-users is fundamental to control a non-invasive brain-actuated intelligent wheelchair in real-world settings.

We demonstrate that three tetraplegic spinal-cord injury users could be trained to operate a non-invasive, self-paced thought-controlled wheelchair and execute complex navigation tasks. However, only the two users exhibiting increasing decoding performance and feature discriminancy, significant neuroplasticity changes and improved BMI command latency, achieved high navigation performance.

In addition, we show that dexterous, continuous control of robots is possible through low-degree of freedom, discrete and uncertain control channels like a motor imagery BMI, by blending human and artificial intelligence through shared-control methodologies.

We posit that subject learning and shared-control are the key components paving the way for translational non-invasive BMI.
