Summary: A new audio technique allows people to hear ultrasonic sounds at frequencies above 20,000 Hz and simultaneously perceive the direction the noise is coming from.

Source: Aalto University

Humans can observe what and where something happens around them with their hearing, as long as sound frequencies lie between 20 Hz and 20 000 Hz. Researchers at Aalto University have now developed a new audio technique that enables people to also hear ultrasonic sources that generate sound at frequencies above 20,000 Hz with simultaneous perception of their direction.

The results have been published in Scientific Reports on 2 June 2021.

‘In our study, we used bats in their natural habitat as sources of ultrasonic sound. With our new technique, we can now hear the directions-of-arrival of bat sounds, which means we can track bats in flight and hear where they are – we’re essentially giving ourselves super hearing,’ says Professor Ville Pulkki from Aalto University.

Small devices have been used before to listen to bats but previous versions haven’t allowed listeners to locate the bats, just hear them. With their device the researchers record ultrasound using an array of microphones flush mounted and uniformly distributed on the surface of a small sphere.

This shows a test participant
The spherical array has 6 microphones sensitive to ultrasound. The ultrasounds are played back to the headphones so that the listener can detect the direction of their source correctly. Credit: Ville Pulkki/Aalto University

After the signal has been pitch-shifted to audible frequencies, the sound is played back on the headphones immediately. Currently, the pitch-shifting is performed on a computer, but, in the future, it could be done with electronics attached to the headphones.

‘A sound-field analysis is performed on the microphone signals, and as a result we obtain the most prominent direction of the ultrasonic sound field and a parameter that suggests that the sound comes only from a single source. After this, a single microphone signal is brought to the audible frequency range of human hearing and its single-source signal is played back on the headphones so that the listener can perceive the source from the direction the sound was analysed to arrive,’ Pulkki says.

On top of its popular appeal, the technique has tangible real-world applications.

Credit: Ville Pulkki

‘In science and art, people have always been interested in how they could improve their senses. Finding sources of ultrasonic sound is also useful in many practical situations, such as finding leaks in pressurised gas pipes. Minor pipe leaks often produce strong ultrasound emissions not detected by normal hearing. The device allows us to spot the sound source quickly,’ Pulkki explains.

‘Sometimes, damaged electrical equipment also emit ultrasound, and the device could be used for locating faulty equipment faster in places such as data centres,’ he continues.

About this auditory neuroscience research news

Source: Aalto University
Contact: Ville Pulkki – Aalto University
Image: The image is credited to Ville Pulkki

Original Research: Open access.
Superhuman spatial hearing technology for ultrasonic frequencies” by Ville Pulkki et al. Scientific Reports


Superhuman spatial hearing technology for ultrasonic frequencies

Ultrasonic sources are inaudible to humans, and while digital signal processing techniques are available to bring ultrasonic signals into the audible range, there are currently no systems which also simultaneously permit the listener to localise the sources through spatial hearing.

Therefore, we describe a method whereby an in-situ listener with normal binaural hearing can localise ultrasonic sources in real-time; opening-up new applications, such as the monitoring of certain forms of wild life in their habitats and man-made systems. In this work, an array of ultrasonic microphones is mounted to headphones, and the spatial parameters of the ultrasonic sound-field are extracted.

A pitch-shifted signal is then rendered to the headphones with spatial properties dictated by the estimated parameters. The processing provides the listener with the spatial cues that would normally occur if the acoustic wave produced by the source were to arrive at the listener having already been pitch-shifted.

The results show that the localisation accuracy delivered by the proof-of-concept device implemented here is almost as good as with audible sources, as tested both in the laboratory and under conditions in the field.
