Extra Short Nanowires Best for Brain

If in the future electrodes are inserted into the human brain – either for research purposes or to treat diseases – it may be appropriate to give them a ‘coat’ of nanowires that could make them less irritating for the brain tissue. However, the nanowires must not exceed a certain length, according to new research from Neuronano Research Center at Lund University in Sweden.

This is the conclusion from an experiment in which the long-term effects of nanowires of different sizes were tested. The nanowires were mixed into a saline solution that was injected into the brains of lab animals, and the results were compared with an injection of saline alone.

The nanowires that were only 2 micrometres long did not have any greater effect on the brain tissue than the pure saline solution, whereas nanowires of 5 and 10 micrometres caused inflammation in the surrounding brain tissue. After a year, there were also fewer nerve cells remaining in the vicinity of the longest nanowires, which suggests that over time they had had a neurotoxic effect.

“We also saw clumps of dead cells containing nanowires, especially with the longer wires. These are probably immune system cells that have tried to neutralize the foreign body. The cells in the immune system’s ‘cleaning patrols’ are often up to 10 micrometres in diameter. They are therefore not able to enclose the long nanowires and die in the process”, said Cecilia Eriksson Linsmeier.

Dr Eriksson Linsmeier is a researcher at the Neuronano Research Center, an interdisciplinary centre at Lund University where researchers in medicine, says engineering and science collaborate to develop electrodes that can be inserted into the brain. This technology can already help patients with Parkinson’s disease and epilepsy. However, current electrodes are quite large and stiff, which over time causes scar tissue to form in the brain, in turn reducing the electrodes’ capacity to influence the nerve cells.

The researchers at the Neuronano Research Center therefore want to develop electrodes that are both smaller and more flexible. They also want to furnish the electrodes with a coating of nanowires, which could produce both a more tissue-friendly surface and better registration of signals from the nerve cells. However, it is important that the nanowires do not damage the tissue if they were to break off from the electrode.

The image shows the nanowires in a neuron.
The nanowires that were only 2 micrometres long did not have any greater effect on the brain tissue than the pure saline solution, whereas nanowires of 5 and 10 micrometres caused inflammation in the surrounding brain tissue. Image credit: The researchers/Biomaterials.

“We have studied a worst case scenario, in which the nanowires break off from the electrode and spread through the brain tissue. In order to proceed with research on brain implants, we must be able to prevent all possible side-effects”, said Cecilia Eriksson Linsmeier.

For the same reason, the study was allowed to continue for an unusual length of time. The effect of the nanowires on the animals was studied both twelve weeks and one year after the injection of the nanowires into the brain. In this context, a year is an extremely long time frame – half the lifespan of a rat.

“A lot of changes take place in the brain as the animal ages. We also found that the long nanowires had certain effects that were not seen until after a year. The short nanowires, on the other hand, did not produce any obvious harmful effects either in the short or the long term”, said Dr Eriksson Linsmeier.

She believes that the group’s findings could be of significance both for future electrodes and in other contexts, such as the development of nanoparticles as drug carriers. This will most probably also require the particles to be small enough not to trigger an immune response.

About this neurotech research

Contact: Cecilia Eriksson Linsmeier – Lund University
Source: Lund University press release
Image Source: The image is credited to the researchers/Biomaterials and is adapted from the Lund University press release
Original Research: Full open access research for “Size-dependent long-term tissue response to biostable nanowires in the brain” by Lina Gällentoft, Lina M.E. Pettersson, Nils Danielsen, Jens Schouenborg, Christelle N. Prinz, and Cecilia Eriksson Linsmeier in Biomaterials. Published online December 16 2014 doi:10.1016/j.biomaterials.2014.11.051

Open Access Neuroscience Abstract

Size-dependent long-term tissue response to biostable nanowires in the brain

Nanostructured neural interfaces, comprising nanotubes or nanowires, have the potential to overcome the present hurdles of achieving stable communication with neuronal networks for long periods of time. This would have a strong impact on brain research. However, little information is available on the brain response to implanted high-aspect-ratio nanoparticles, which share morphological similarities with asbestos fibres. Here, we investigated the glial response and neuronal loss in the rat brain after implantation of biostable and structurally controlled nanowires of different lengths for a period up to one year post-surgery. Our results show that, as for lung and abdominal tissue, the brain is subject to a sustained, local inflammation when biostable and high-aspect-ratio nanoparticles of 5 μm or longer are present in the brain tissue. In addition, a significant loss of neurons was observed adjacent to the 10 μm nanowires after one year. Notably, the inflammatory response was restricted to a narrow zone around the nanowires and did not escalate between 12 weeks and one year. Furthermore, 2 μm nanowires did not cause significant inflammatory response nor significant loss of neurons nearby. The present results provide key information for the design of future neural implants based on nanomaterials.

“Size-dependent long-term tissue response to biostable nanowires in the brain” by Lina Gällentoft, Lina M.E. Pettersson, Nils Danielsen, Jens Schouenborg, Christelle N. Prinz, and Cecilia Eriksson Linsmeier in Biomaterials doi:10.1016/j.biomaterials.2014.11.051 .
