Scientists Replay Movie Encoded in DNA

Summary: Researchers have encoded a ‘primitive’ video from the DNA in living cells. The Nature study reports this is the first step towards a ‘molecular recorder’ that could make it possible to get read-outs of changing internal states of neurons as they develop in the brain.

Source: NIH/NIMH

Molecular Recorder’ would reveal secrets of brain development.

For the first time, a primitive movie has been encoded in – and then played back from – DNA in living cells. Scientists funded by the National Institutes of Health say it is a major step toward a “molecular recorder” that may someday make it possible to get read-outs, for example, of the changing internal states of neurons as they develop.

“We want to turn cells into historians,” explained neuroscientist Seth Shipman, Ph.D., a post-doctoral fellow at Harvard Medical School, Boston. “We envision a biological memory system that’s much smaller and more versatile than today’s technologies, which will track many events non-intrusively over time.”

Shipman, Harvard’s Drs. George Church, Jeffrey Macklis and Jeff Nivala report on their proof-of-concept for a futuristic “molecular ticker tape” online July 12, in the journal Nature. The work was funded by NIH’s National Institute of Mental Health, National Institute of Neurological Disorders and Stroke, and the National Human Genome Research Institute.

The ability to record such sequential events like a movie at the molecular level is key to the idea of reinventing the very concept of recording using molecular engineering, say the researchers. In this scheme, cells themselves could be induced to record molecular events – such as changes in gene expression over time – in their own genomes. Then the information could be retrieved simply by sequencing the genomes of the cells it is stored in.

“If we had those transcriptional steps, we could potentially use them like a recipe to engineer similar cells,” added Shipman. “These could be used to model disease – or even in therapies.”

For starters, the researchers had to show that DNA can be used to encode not just genetic information, but any arbitrary sequential information into a genome. For this they turned to the cutting-edge, NIH-funded gene editing technology CRISPR. They first demonstrated that they could encode and retrieve an image of the human hand in DNA inserted into bacteria. They then similarly encoded and reconstructed frames from a classic 1870s race horse in motion sequence of photos – an early forerunner of moving pictures.

Image shows a still from the video.

The researchers had previously shown that they could use CRISPR to store sequences of DNA in bacteria. CRISPR is a group of proteins and DNA that act as an immune system in some bacteria, vaccinating them with genetic memories of viral infections. When a virus infects a bacterium, CRISPR cuts out part of the foreign DNA and stores it in the bacteria’s own genome. The bacterium then uses the stored DNA to recognize the virus and defend against future attacks. NeuroscienceNews.com image is adapted from the NIMH video.

The researchers had previously shown that they could use CRISPR to store sequences of DNA in bacteria. CRISPR is a group of proteins and DNA that act as an immune system in some bacteria, vaccinating them with genetic memories of viral infections. When a virus infects a bacterium, CRISPR cuts out part of the foreign DNA and stores it in the bacteria’s own genome. The bacterium then uses the stored DNA to recognize the virus and defend against future attacks.

“The sequential nature of CRISPR makes it an appealing system for recording events over time,” explained Shipman.

The researchers then similarly translated five frames from the race horse in motion photo sequence into DNA. Over the course of five days, they sequentially treated bacteria with a frame of translated DNA. Afterwards, they were able to reconstruct the movie with 90 percent accuracy by sequencing the bacterial DNA.


For the first time, a primitive movie has been encoded in – and then played back from – DNA in living cells. Scientists funded by the National Institutes of Health say it is a major step toward a “molecular recorder” that may someday make it possible to get read-outs, for example, of the changing internal states of neurons as they develop. Neuroscientist Seth Shipman, Ph.D., of Harvard Medical School, explains the study.

Although this technology could be used in a variety of ways, the researchers ultimately hope to use it to study the brain.

“We want to use neurons to record a molecular history of the brain through development,” said Shipman. “Such a molecular recorder will allow us to eventually collect data from every cell in the brain at once, without the need to gain access, to observe the cells directly, or disrupt the system to extract genetic material or proteins.”

About this neuroscience research article

Source: Jules Asher – NIH/NIMH
Image Source: NeuroscienceNews.com image is adapted from the NIMH video.
Video Source: Video credited to NIMH.
Original Reserch: Abstract for “CRISPR–Cas encoding of a digital movie into the genomes of a population of living bacteria” by Seth L. Shipman, Jeff Nivala, Jeffrey D. Macklis & George M. Church in Nautre. Published online July 12 doi:10.1038/nature23017

Cite This NeuroscienceNews.com Article
NIH/NIMH “Purpose in Life by Day Linked to Better Sleep at Night.” NeuroscienceNews. NeuroscienceNews, 12 July 2017.
<http://neurosciencenews.com/dna-encoding-7075/>.
NIH/NIMH (2017, July 12). Purpose in Life by Day Linked to Better Sleep at Night. NeuroscienceNew. Retrieved July 12, 2017 from http://neurosciencenews.com/dna-encoding-7075/
NIH/NIMH “Purpose in Life by Day Linked to Better Sleep at Night.” http://neurosciencenews.com/dna-encoding-7075/ (accessed July 12, 2017).

Abstract

CRISPR–Cas encoding of a digital movie into the genomes of a population of living bacteria

DNA is an excellent medium for archiving data. Recent efforts have illustrated the potential for information storage in DNA using synthesized oligonucleotides assembled in vitro. A relatively unexplored avenue of information storage in DNA is the ability to write information into the genome of a living cell by the addition of nucleotides over time. Using the Cas1–Cas2 integrase, the CRISPR–Cas microbial immune system stores the nucleotide content of invading viruses to confer adaptive immunity. When harnessed, this system has the potential to write arbitrary information into the genome. Here we use the CRISPR–Cas system to encode the pixel values of black and white images and a short movie into the genomes of a population of living bacteria. In doing so, we push the technical limits of this information storage system and optimize strategies to minimize those limitations. We also uncover underlying principles of the CRISPR–Cas adaptation system, including sequence determinants of spacer acquisition that are relevant for understanding both the basic biology of bacterial adaptation and its technological applications. This work demonstrates that this system can capture and stably store practical amounts of real data within the genomes of populations of living cells.

“CRISPR–Cas encoding of a digital movie into the genomes of a population of living bacteria” by Seth L. Shipman, Jeff Nivala, Jeffrey D. Macklis & George M. Church in Nautre. Published online July 12 doi:10.1038/nature23017
